| Place of Origin: | GUANGZHOU ,CHINA |
| Brand Name: | LANGKING |
| Certification: | CE |
| Model Number: | Y047 without door with small light |
Without roof 4 Wheel 4 Person Electric Club Car Golf Carts With 48V Battery Powered
Model Y047 without roof with light
| HS CODE | 8703101900 |
| Qty/20'GP (Disassembled) | 2 units |
| Qty/40'HQ (Disassembled) | 12 units |
| Specifications | |
| Performance: | |
| Passenger capacity | 4 seats |
| Max.Speed | 24km/h |
| Range(loaded) | 80km |
| Climbing Ability(loaded) | 25% |
| Braking Distance | ≤4.3m |
| Min.Turning Radius | 5m |
| Min.Clearance | 105mm |
| Recharge time | 8~10h |
| Dimensions | |
| L×W×H | 3280×1220×1950mm |
| F/R Tread | 870/980mm |
| Axle Distance | 2450mm |
| Curb Weight | 640kg |
| Max. loading | 340kg |
| Standard Configurations | |||
| Motor | 48V/3KW DC motor | ||
| Controller | 48V/300A | ||
| Battery | Maintenance-free battery 6V*8PCS | ||
| Body & Roof | ABS Plastic/ PP material | ||
| Windshield | one - piece see-through POLYCARBONATE glass | ||
| Seats | Sponge + artificial leather | ||
| Rear view mirror | 2pcs | ||
| Bumper | Front and rear Bumper | ||
| Tire | golf course use 18×8.50-8 6PR | ||
| Chassis | Welded tubular steel with rust-proof powder coated paint | ||
| Steering | Single reduction rack and pinion | ||
| Front Suspension | non-independent suspension, leaf spring+Barrel type hydraulic shock absorber | ||
| Rear suspension | non-independent suspension, leaf spring+Barrel type hydraulic shock absorber | ||
| Lighting system | 2 headlights, 2 rear brake lights | ||
| Sound system | Horn, back-up buzze | ||
| Brake system | Dual rear wheel mechanical self-adjusting drum brakes. Automatic park brake | ||
| Charger | Automatic high efficiency pulse, Output:48V/25A, Input AC 220V/50HZ | ||
| Dashboard | 4 cups cup holders+1 phone holder, electricity meter, speedometer, Headlight switch, turn signal switch | ||
| Color Option | White, Grey, Navy, Red, Khaki, Purple, Green etc. | ||
Product Showing:
Product Application:
Such new designed tourist buses are easy to handle & maintain.
It is designed for non-public road use.
It is widely used in amusement park, city tourist line, upscale site, scenic spots as transportation facility.
* Golf Course,Hotel,Campus,Park,Airport,Tourist Resorts,Mountain Area,Wedding Place and so on.
Our Service:
a)We can change cars’ appearances and/or colors according to your demands.
b)We can replace the driving motor with gasoline engine or diesel engine, or add solar panels according to your demands.
We provide 12 months warranty since the delivery date.
We promise to answer your questions about handling, maintaining or repairing within 12 hours.
If there is any quality problem, we promise to deliver the spare parts within 5 working days.
FAQ:
1. What's your warranty time?
All Langking golf cart sold by us are quality guaranteed.
We provide 1 year warranty for main parts to our electric vehicles when you get them.
2. What's the production time?
Normally for 30 working days
3. What's your payment term?
T/T 30% deposit and balance paid before shipment.
