| Place of Origin: | GUANGZHOU ,CHINA |
| Brand Name: | LANGKING |
| Certification: | CE |
| Model Number: | F122 |
MOLDE F122 1.2 TONS ELECTRIC FREIGHT CAR/ELECTRIC TRUCK/ELECTRIC VAN 72V/5KW 2 SEATS USING FACTORY
| Qty/20'GP (Assembled) | 1 unit | |
| Qty/40'GP (Assembled) | 2 units | |
| HS CODE | 8709119000 | |
| Specifications | ||
| Performance: | ||
| Passenger capacity | 2 seats | |
| Max.Speed | 28km/h | |
| Range(loaded) | 90km | |
| Climbing Ability(loaded) | 12% | |
| Braking Distance | ≤4.5m | |
| Min.Turning Radius | 6.5m | |
| Min.Clearance | 150mm | |
| Recharge time | 8~10h | |
| Dimensions | ||
| L×W×H | 4620×1470×2050 mm | |
| F/R Tread | 1280/1270mm | |
| Axle Distance | 2650mm | |
| Curb Weight | 1250kg | |
| Max. loading | 1200kg | |
| Standard Configurations | ||
| Motor | 72V/5KW DC motor | |
| Controller | 72V 400A controller | |
| Battery | Batteries 6V*12 pcs | |
| Body | High impact fiber glass + Sheet metal plastform coaming | |
| Windshield | See-through Laminated glass | |
| Seats | Sponge + artificial leather | |
| Rear view mirror | 2pcs | |
| Bumper | Front and rear Bumper | |
| Tire | 155/80R12 Radial tire with aluminium alloy wheel | |
| Chassis | Welded tubular steel with rust-proof powder coated paint | |
| Steering | Single reduction rack and pinion | |
| Front Suspension | The MacPherson Strut suspension system, coil spring+shock absorber | |
| Rear suspension | Transmission shaft Input Integrated rear axle Leaf spring+shock absorber non-independent suspension | |
| Lighting system | headlights, front turn signals, rear turn signals and rear brake lights | |
| Sound system | Radio and MP3 player; Speaker | |
| Brake system | 4-wheel hydraulic drum brake system + handbrake | |
| Charger | Automatic high efficiency pulse, Output:72V/25A, Input AC 220V/50-60 HZ | |
| Dashboard | Voltameter, ammeter, turn signal indicator, headlight indicator, emergency switch, Headlight switch, turn signal switch, wiper switch, horn button | |
| Color Option | White, Grey, Navy, Red, Khaki, Purple, Green etc. | |
FAQ
1, what's your warranty time?
All Langking golf cart sold by us are quality guaranteed.
We provide 1 year warranty for main parts to our electric vehicles when you get them.
2, What's the production time?
Normally for 30 working days
3, What's your payment term?
T/T 30% deposit and balance paid before shipment
