| Place of Origin: | Guangzhou, China |
| Brand Name: | Langking |
| Certification: | CE |
| Model Number: | Y045 |
| Document: | Product Brochure PDF |
Hot sales red color 4 seats electric Club car ,electric fire engine ,mini car model Y045
Electric Club Car is a specially designed and developed for a special department patrol passenger car, which is divided into ordinary patrol car and closed type, ordinary patrol car can be divided into ordinary type and luxury type . It is especially suitable for public security patrols, pedestrian streets, golf courses, tourist attractions, real estate , all kinds of large enterprises, institutions, parks, entertainment venues, stadiums, universities, hospitals, nursing homes, ports and so on.
Detail Specification
| Performance: | |
| Passenger capacity | 4 seats |
| Max.Speed | 28 km/h |
| Range(loaded) | 85 km |
| Climbing Ability(loaded) | 25% |
| Braking Distance | ≤4m |
| Min.Turning Radius | 4.5m |
| Min.Clearance | 105mm |
| Recharge time | 8~10h |
| Dimensions | |
| L×W×H | 3150×1520×1860mm |
| F/R Tread | 1150/1200mm |
| Axle Distance | 1780mm |
| Curb Weight | 625kg |
| Max. loading | 340kg |
| Standard Configurations | |||
| Motor | 48V/3KW DC motor | ||
| Controller | 48V | ||
| Battery | Maintenance-free battery 6V /170Ah*8PCS | ||
| Body & Roof | High impact fiber glass | ||
| Windshield | See-through Laminated glass | ||
| Seats | High impact fiber glass | ||
| Rear view mirror | 2pcs | ||
| Bumper | Front | ||
| Tire | 155/80 R12 Radial tire (Auto tire) | ||
| Chassis | Welded tubular steel with rust-proof powder coated paint | ||
| Steering | Recirculating ball steering gear | ||
| Front Suspension | The MacPherson Strut suspension system, coil spring+shock absorber | ||
| Rear suspension | Leaf spring+shock absorber non-independent suspension | ||
| Lighting system | 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights,Police light bar | ||
| Sound system | Radio and MP3 player; Speaker | ||
| Brake system | 4-wheel hydraulic drum brake system + handbrake | ||
| Charger | Automatic high efficiency pulse, Output:48V/25A, Input AC 220V/50HZ | ||
| Dashboard | Forward/reverse switch, turn signal indicator, ignition key, ammeter, speedometer, emergency switch, headlight switch, windscreen wiper switch, horn button, radio and tape player,electric power consumption indicator | ||
| Color Option | White, Grey, Navy, Red, Khaki, Purple, Green etc. | ||
Feather of electric cart:
1.High quality: Quality is first, in our company it is not allowed to achieve low price by decreasing the quality.
2.Low Price: We have mature production technology and almost 18 years , we have competitive factory.
3. Fast delivery and Low MOQ.
FAQ
Q1.Are there any other options for this car?
A:Yes, different body colors, Seat belts, sunshade Cover, MP3 player, Spare tire, with door/without door, Custom logo, or any other optional as your requirement.
Q2.How about the delivery time?
A:Generally, it will take 15 to 25 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order
Q3.Do you provide operational manual?
A:Yes, we provide them. The operational manual will be sent together with the vehicles.
Q4.What's your payment term?
A:T/T 30% deposit and balance before shipment. We'll show you the photos of the products and packages before you pay the balance.
Q5.Do you provide Trade Assurance via Alibaba?
A:Yes, we do. Trade Assurance orders is welcomed!
Our Services
1. Strict quality control step by step.
2.After market service available.
3. Spare part available.
4. Company’s own shipping port storage warehouse and pre-shipment inspection by our professional engineer.
5.24 hours online service.
