| Place of Origin: | Guangzhou |
| Brand Name: | Langking |
| Model Number: | Tour Cart |
Electric Spare Parts Electric Club Cart Free Maintance Battery 6V 170AH for Shuttle Bus
Part Name:Dry Battery 6V 200AH
Professional to provide domestic manufacturers of electric vehicle repair parts
Applicable models:Golf Carts Club Cart
Packing :Carton Box
Air Transportation International Express :DHL,TNT,FedEx,UPS,EMS,ETC.
Product Showing:
Detail of the Battery:
| 1. Functional Parameter | 5. Environment Temperature | ||
| Nominal Voltage | 6V | Discharge Temperature | -20~50℃ |
| Nominal Capacity (10 hour rate) | 200Ah | Charge Temperature | -10~50℃ |
| Number of Cells | 3cells | Storage Temperature | -20~60℃ |
| 2. Rated Capacity at 25℃ (77° F) | 6. Inner Resistance & Max . Discharge Current | ||
| 10 hour rate (0.1C, 1.80V/cell) | 200Ah | Fully Charged battery at 25℃ (77° F) | 1.75mΩ |
| 3 hour rate (0.25C, 1.75V/cell) | 152Ah | Max. Discharge Current | 1900A (5s) |
| 1 hour rate (0.55C, 1.60V/cell) | 95Ah | Short Circuit Current | 6300A |
| 3. Capacity affected by Temperature (10 hour rate) | 7. Self-discharge at 25℃ (77° F) | ||
| 40℃ (104° F) | 102% | Capacity after 3 month storage | 92% |
| 25℃ (77° F) | 100% | Capacity after 6 month storage | 84% |
| 0℃ (32° F) | 90% | Capacity after 9 month storage | 74% |
| -15℃ (5° F) | 70% | Capacity after 12 month storage | 65% |
| 4. Dimension and Weight | 8. Constant voltage charging at 25℃ (77° F) | ||
| Length | 260mm | Cyclic use | 7.20~7.35V |
| Width | 180mm | Maximum charging current | 40A |
| Height | 277mm | Temperature compensation | -30mV/℃ |
| Total Height | 280mm | Float use | 6.8~6.9V |
| Reference Weight | 34.5kg | Temperature compensation | -20mV/℃ |
Key Features :
♦Long service life according to EUROBAT Classification
♦Up to 3700 deep discharge cycles
♦High gas recombination efficiency
♦Wide suitability of ambient temperature range
♦Low self discharge
Applications :
♦Solar and wind energy storage system
♦EPS and UPS battery backup
♦Signal system , emergency lighting system , security system
♦Telecommunication Equipment
♦Power plant and transmission system
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A: Sample needs 3-5 days if we have in stock.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
