| Place of Origin: | Guangzhou |
| Brand Name: | Langking |
| Certification: | CE |
| Model Number: | Y065A |
Orange Colour Powerful Electric Golf Cart 6 Person Steel Framework Electric Club Car
Performance of Model Y065A Electric Club Car Six Seats
| Qty/20'GP (Assembled) | 2 units |
| Qty/40'GP (Assembled) | 12units |
Specifications:
| Passenger capacity | 6 seats |
| Max.Speed | 24km/h |
| Range(loaded) | 80km |
| Climbing Ability(loaded) | 25% |
| Braking Distance | ≤4.5m |
| Min.Turning Radius | 6m |
| Min.Clearance | 105mm |
| Recharge time | 8~10h |
Dimensions
| L×W×H | 4050×1220×1950mm |
| F/R Tread | 870/980mm |
| Axle Distance | 3220mm |
| Curb Weight | 720kg |
| Max. loading | 480kg |
Standard Configurations
| Motor | 48V/3KW DC motor | ||
| Controller | 48V/300A | ||
| Battery | Maintenance-free battery 6V /170Ah*8PCS | ||
| Body & Roof | ABS Plastic/ PP material | ||
| Windshield | one - piece see-through POLYCARBONATE glass | ||
| Seats | Sponge + artificial leather | ||
| Rear view mirror | 2pcs | ||
| Bumper | Front and rear Bumper | ||
| Tire | golf course use 18×8.50-8 6PR | ||
| Chassis | Welded tubular steel with rust-proof powder coated paint | ||
| Steering | Single reduction rack and pinion | ||
| Front Suspension | non-independent suspension, leaf spring+Barrel type hydraulic shock absorber | ||
| Rear suspension | non-independent suspension, leaf spring+Barrel type hydraulic shock absorber | ||
| Lighting system | 2 headlights, 2 rear brake lights | ||
| Sound system | Horn, back-up buzze | ||
| Brake system | Dual rear wheel mechanical self-adjusting drum brakes. Automatic park brake | ||
| Charger | Automatic high efficiency pulse, Output:48V/25A, Input AC 220V/50HZ | ||
| Dashboard | 4 cups cup holders+1 phone holder, electricity meter, speedometer, Headlight switch, turn signal switch | ||
| Color Option |
White, Grey, Navy, Red, Khaki, Purple, Green etc.
|
||
Product Showing:
Application:
Electric cars offer advantages of both an economic and technical nature. Running costs are lower as, unlike combustion vehicles, there aren't any parts subject to wear, and the motor works in a cleaner, more simple manner than traditional engines.
But there are also other benefits, such as the possibility to move freely even in areas with traffic limitations because these vehicles are non-polluting. This is a huge advantage nowadays, given the ever increasing traffic bans. Consumption is very low.
It can used for Golf Course,Hotel,Campus,Park,Airport,Tourist Resorts,Museum,Mountain Area,Wedding Place and so on.
FAQ:
1. What's your warranty time?
All Langking golf cart sold by us are quality guaranteed.
We provide 1 year warranty for main parts to our electric vehicles when you get them.
2. What's the production time?
Normally for 30 working days
3. What's your payment term?
T/T 30% deposit and balance paid before shipment.
4.Can we also purchase the parts
Yes,if you do maintainess service,you can also buy parts from us.We are the profeesional for the aftersales.
